Description
The DI-804HV is a 4-port Ethernet Broadband Router with VPN (Virtual Private Network) capabilities. The DI-804HV is ideal if you’re creating your home or small business network, or if you’re a more advanced user looking for additional management settings.
D-Link, the worldwide leader in innovative home and business networking, sets a new standard for broadband router performance with the
Express EtherNetwork DI-804HV.
The DI-804HV is a 4-port Ethernet Broadband Router with VPN (Virtual Private Network) capabilities. The VPN feature allows users to securely connect multiple computers over the Internet. It also features 10/100Mbps Auto MDIX Ethernet ports allowing CAT 5 cable (straight-through or crossover) to work with the DI-804HV.
The DI-804HV is ideal if you’re creating your home or small business network, or if you’re a more advanced user looking for additional management settings.
The DI-804HV includes a new setup wizard and D-Link’s easy-to-use web-based graphical user interface (GUI) to help users configure network settings with a few simple clicks. With its built-in firewall protection, this router will also help to prevent unwanted Internet intruders from accessing your private network.
So, whether you’re a college student who wants to network with friends and roommates, an executive working at home or in a small office, or a concerned parent who just wants to have more control over how your children access the Internet, the D-Link Express EtherNetwork DI-804HV is the networking solution for you.
Features
- Firewall Security & Parental Control
- Multiple VPN Tunnels
- OS Independent
Specifications
Network Interface
| Four 10/100 Ethernet LAN Ports - RJ-45 connectors
- 10/100Mbps auto-negotiation
- Auto-crossover cable adaptation
One 10/100 Ethernet WAN Port - RJ-45 connectors
- 10/100Mbps auto-negotiation
- Auto-crossover cable adaptation
- One male DB-9 com port
| Standards
| - IEEE 802.3 10Base-T Ethernet
- IEEE 802.3u 100Base-TX Fast Ethernet
- IEEE 802.3x Flow Control
- ANSI/IEEE 802.3 NWay Auto- Negotiation
| Device Management
Security
| - Denial of Service (DoS)
- Stateful Packet Inspection (SPI)
- Activities Logging
- NAT
- DMZ
- Filtering
| | VPN Support | - IPSec (40 IPSec Tunnels)
- IP Authentication Header (AH)
- IP Encapsulating Security Payload (ESP)
- Internet Key Exchange (IKE)
authentication and Key Management - Authentication (MD5 / SHA-1)
- NULL/DES/3DES Encryption Algorithm
and their use with IPSec - Internet Security Association and Key
- Management Protocol
- Main and Aggressive mode
| | Physical Specifications | - Dimensions (WxHxD): 7.56 x 4.65 x 1.22 in (192 x 48 x 31 mm)
- Weight: 0.7lbs (0.3 kg)
| LEDs
| - Power
- M1 (Indicates Active System)
- M2 (Indicates Internet Connection)
- COM (for dial-up modem)
- (1) WAN Link/Activity
- (4) LAN Link/Activity
| Temperature
| Operating: 41° to 131°F (5° to 55°C) | Humidity, non-condensing
| Operating: 10% to 90% RH | Power Requirements
| - Universal AC input: 100-110 VAC, 5 Volt ± 5% / 2.5 A
- Internal Universal Power Supply
| EMC/Safety Compliances
| EMI: - FCC Class B
- ETS 300 328
- ETS 300 826
- EN60950
- CE-Mark
- BSMI
| Warranty
| - Limited 1 Year Warranty for as long
as the original customer/end user
owns the product. - Free 24/7 Technical Support
|
| Part Number: | DI-804HV | | Description: | Ethernet Broadband VPN Router |
|
